Extraordinary Custom Coil Spiral Cable 80C 300V

Brand Name : Spiral Cable

Model Number : spiral-cable-004

Certification : UL, CUL, CSA, AWM, CE

Place of Origin : Dongguan, China

MOQ : 200 PCS

Price : USD0.25~0.68 per piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 800,000pcs per month

Delivery Time : 10 days for ready goods

Packaging Details : 200pcs per carton box

Category : Coil spiral cable

Feature : Extraordinary custom make

Rated Temperature : 80C Degrees

Rated Voltage : 300V

Dimensions : To be customized per request

Standard : RoHS Compliant

Connductor Material : Oxygen free copper wires

Sheath Material : Thermoplastic TPU

Contact Now

Extraordinary Custom Coil Spiral Cable 80C 300V

As the professional spiral cable manufacturer, Tongheng guarantees good quality. All spiral cable products are manufactured strictly following customer's designed requirement. Extraordinary custom coil spiral cable exhibits the great performance.

Here below is the product properties:

Conductors quantity: 2~50C;

Executed standard: UL758;

Performance: high flexibility and long flex life use;

100% RoHS & Reach compliant.

Product parameters:

Spiral Cable	Conductor Structure	Insulation Thickness	Nominal Diameter	Screened Coverage	Sheath Thickness	Overall Diameter	Conductor Resistance
Spiral Cable	No/mm	mm	mm	%	mm	mm	Ω/KM(20℃)
2C	7/0.100	0.76	1.90	≥65	1.15	6.70	381.00
2C	7/0.127	0.76	2.00	≥65	1.15	7.00	239.00
2C	7/0.16	0.76	2.10	≥65	1.15	7.10	150.00
2C	11/0.16	0.76	2.20	≥65	1.15	7.30	94.20
2C	17/0.16	0.76	2.40	≥65	1.15	7.70	59.40
2C	21/0.178	0.76	2.50	≥65	1.15	8.10	36.70
2C	34/0.178	0.76	2.80	≥65	1.15	8.70	23.20
2C	26/0.25	0.76	3.10	≥65	1.15	10.90	14.60
3C	7/0.100	0.76	1.90	≥65	1.15	8.60	381.00
3C	7/0.127	0.76	2.00	≥65	1.15	8.80	239.00
3C	7/0.16	0.76	2.10	≥65	1.15	9.00	150.00
3C	11/0.16	0.76	2.20	≥65	1.15	9.20	94.20
3C	17/0.16	0.76	2.40	≥65	1.15	9.60	59.40
3C	21/0.178	0.76	2.50	≥65	1.15	10.10	36.70
3C	34/0.178	0.76	2.80	≥65	1.15	10.70	23.20
4C	7/0.100	0.76	1.90	≥65	1.15	8.80	381.00
4C	7/0.127	0.76	2.00	≥65	1.15	9.00	239.00
4C	7/0.16	0.76	2.10	≥65	1.15	9.30	150.00
4C	11/0.16	0.76	2.20	≥65	1.15	9.60	94.20
4C	17/0.16	0.76	2.40	≥65	1.15	10.00	59.40
4C	21/0.178	0.76	2.50	≥65	1.15	10.50	36.70
5C	7/0.100	0.76	1.90	≥65	1.15	9.10	381.00
5C	7/0.127	0.76	2.00	≥65	1.15	9.40	239.00
5C	7/0.16	0.76	2.10	≥65	1.15	9.50	150.00
5C	11/0.16	0.76	2.20	≥65	1.15	9.90	94.20
5C	17/0.16	0.76	2.40	≥65	1.15	10.60	59.40
6C	7/0.100	0.76	1.90	≥65	1.15	9.50	381.00
6C	7/0.127	0.76	2.00	≥65	1.15	9.80	239.00
6C	7/0.16	0.76	2.10	≥65	1.15	10.10	150.00
6C	11/0.16	0.76	2.20	≥65	1.15	10.40	94.20

Product Images:

Extraordinary Custom Coil Spiral Cable 80C 300V

Tag: spiral cable, coil cable

Extraordinary Custom Coil Spiral Cable 80C 300V Images
